產品介紹：
Intel? 6th/7th Gen Core? i7/i5/i3/Pentium?/Celeron? Processor, LGA1151 Socket, TDP up to 95W
| 處理器 Processor | Intel? 6th/7th Gen Core? i7/i5/i3/Pentium?/Celeron? Processor, LGA1151 Socket, TDP up to 95W |
| 芯片組 Chipset | Intel? Q170 Chipset |
| 內存 Memory | Dual Channel, 4 x U-DIMM Slot, DDR4 2133/2400MHz, up to 64GB |
| 圖形 Graphics | Intel? HD Graphics, triple display |
| 存儲 Storage | 4 x SATA3.0, 1 x M.2 2242/2280 (SATA3.0/PCIe3.0x1 supported) |
| 操作系統 OS | 6th Gen CPU : Windows7/8/10, Linux 7th Gen CPU : Windows10, Linux |
| 信賴平臺模塊 TPM | Nuvoton TPM1.2 |
| 網口 Ethernet | 1 x Intel? i219-LM GbE, 1 x Intel? i211-AT (10/100/1000 Mbps) |
| 顯示 Video | 1 x DVI-D: max resolution up to 1920 x 1200@60Hz 1 x VGA: max resolution up to 1920 x 1200@60Hz 1 x DP++: max resolution up to 4096 x 2304@60Hz |
| 音頻 Audio | 1 x Line-in, 1 x Line-out, 1 x Mic-in |
| 串口 COM | 1 x RS232/422/485 (with auto flow control) |
| USB | 6 x USB 3.0, 4 x USB 2.0 (Rear USB ports support Ennoconn USB SR Pro) |
| 按鈕 Button | 1 x Power Button, 1 x Reset Button |
| 指示燈 LED | 1 x Power LED, 1 x HDD LED |
| 擴展接口 Expansion | 2 x PCIe X16 (Gen3, 1 x 16 or 2 x 8 link), 3 x PCIe X4 (X4 link) , 2 x PCI |
| 風扇 FAN | 1 x CPU Fan, 2 x System Fan |
| USB | 3 x USB2.0 (Type-A share USB signal with one USB2.0) |
| GPIO | 1 x 16-bit GPIO |
| 串口 COM | 1 x RS232/422/485, 2 x RS232/485, 2 x RS232 |
| LPT | 1 x LPT |
| PS/2 | 1 x PS/2 (keyboard and mouse) |
| 操作溫度 Operating Temp. | 0℃ ~ 40℃ |
| 存儲溫度Storage Temp. | -20℃ ~ 60℃ |
| 濕度Relative Humidity | 5% ~ 95%, 非凝結狀態Non-condensing |
| 隨機振動 Random Vibration | 5~500Hz, 1Grms (HDD)operation |
| 正弦振動 Sine Vibration | 5~500Hz, 2G Non-operation |
| 機械沖擊 Shock | 10G @ 11ms operation |
| 電源輸入 Power Input | 100~240V(AC) |
| 電源功耗 Power Watt | 300W |
| 外觀 Housing | SGCC |
| 尺寸 Dimension | 200(L) x 430(W) x 330(H)mm |
| 重量 Weight | 9.96kg(約) |
| 安裝方式 Mounting | 壁掛式(Wallmount) |
| 安規認證 Safety Certification | CCC |
